LONGWELL MAINBOARD (1150) H81-AC DDR3 (REV. 3.0) - A0155189

Brand : LONGWELL

Model : H81-AC Rev3.0

CPU Support : Supports 4th generation Intel® Core™ i7 / Core™ i5 / Core™ i3 / Pentium® / Celeron® / Xeon® processors

CPU Brand : Intel

Socket : 1150

Chipset : Intel H81

Memory Support : Support DDR3 1600/1333/1066 MHz Non-ECC, UnBuffered Memory
2 x DIMM Max 16GB

Maximum Memory Bus : 1600

Graphics : Integrated Graphics Processor

Multi Graphic Support : None

Audio : Realtek® ALC 662 Channel High Definition Audio CODEC

Expansion Slots : 1 x PCI Express 2.0 x16 (x16 mode)
1 x PCI Express 2.0 x1

Maximum PCIe Version : PCIe 2.0

Storage : 1 x PCI Express 2.0 x1
1 x PCI Express 2.0 x16 (x16 mode)

M.2 Storage Type Support : NVMe

M.2 Slot : 1

USB : 4 x USB 2.0 Ports
2 x USB 3.0 Ports
1 x F USB 3.0 Gen1 connectors
2 x F USB 2.0 Connector

Internal I/O Connectors : 1 x 24-pin EATX Power Connector
1 x 4-pin ATX 12V Power Connector
1 x CPU Fan Connector
1 x F USB 3.0 Gen1 connectors
2 x F USB 2.0 Connector
1 x Debug
1 x Front Panel Audio Connector (AAFP)
1 x Speaker Connector
1 x System Panel Connecto

Back Panel Connectors : 4 x USB 2.0 Ports
2 x USB 3.0 Ports
1 x HDMI Port
1 x VGA (D-Sub) Port
1 x RJ-45 LAN port
3 x Audio Jacks: Line in / Speaker / Microphone

LAN : 10/100 Mb/s auto negotiation Half/Full duplex capability
Realtek® RTL8105E

Wireless Data Network : None

Form Factor : Micro ATX

H/W Monitoring : N/A

BIOS : N/A

Special Features : N/A

Software Features : N/A

Operating System Support : Microsoft® Window® 7-11

Package Contents : 1 x SATA cable
1 x I/O Rear Panel
1 x User Manual
1 x CD Driver

Dimension (W x D x H) : 21.50 x 17.00 x 0.00 cm

Net Weight : 0.00

Package Dimension (W x D x H) : 27.50 x 23.50 x 5.50 cm

Gross Weight : 0.64

Volume : 3,554.38

ประกัน : 3 ปี
